Freewing Eurofighter Typhoon 90mm EDF Jet- 8S PNP Version
This new 2023 version of the Freewing Eurofighter comes with basic decals pre-applied, however the tiger decals are UNAPPLIED. This allows our customers to have more freedom to choose their own custom decals if so desired.
The Freewing Eurofighter is one of the most unique EDF jets in both looks and function, and now it's available in this all new 8S High Performance version for 2023 and beyond. This is not a retool of the old version. This is a 100% new Eurofighter. There were two big goals for this model. This model had to be fast and it had to be significantly more scale than the old version from years ago. In order to achieve speed and efficiency, a 100% new 8S power system was created for this plane.
The new version of the Eurofighter now includes a 4075-1350Kv brushless inrunner motor with a 100% new 12-blade EDF unit and 120A ESC with 8A/BEC for superior performance and sound. The new Eurofighter includes a thrust reversing function to slow the plane on shorter runways as well as an airbrake which will aid in high alpha maneuvers as well as slowing the plane down after landing.
Features:
NEW! Completely redesigned mold from front to back
NEW! Completely new 12-blade factory-balanced EDF combined with 4075-1350Kv brushless inrunner motor produces top end EDF jet performance and realistic jet turbine sound
NEW! 120 Amp Hobbywing ESC with 8A UBEC
NEW! Thrust Reversing function for shorter landings
NEW! Functional scale air brake for high alpha and help with shorter runways
NEW! Tiger decals now come unapplied to allow customers the flexibility to choose their own custom decals if desired
Scale weapon set and pylons (10 total) included
Flight surfaces are controlled with 9g and 17g digital metal gear servos for precise movement, strength and long life
Bright LED landing and navigation lights for enhanced realism and dawn/dusk maneuvers
Electronic retractable landing gear with CNC shock-absorbing struts and metal trunnions
Scale, sequenced gear doors provide added realism and improved aerodynamics
Upgraded pushrod clevis and metal ball head connectors provide a robust connection between servo and control surface and eliminate "play"
Nylon hinges on all control surfaces (superior to foam hinges)
Includes:
Freewing Eurofighter Typhoon 8S High Performance 90mm EDF Jet - PNP
Servos, EDF, brushless inrunner motor, lights, retracts and ESC all pre-installed
Scale weapon set and pylons (10 total)
PRODUCT SPECIFICATIONS :
Model Scale
N/A
Wingspan
1030mm / 40.5in
Length
1450mm / 57in
Empty Weight
3230g
CG (Center of Gravity)
215mm from the leading edge of the wing's root
Power System
4075-1350Kv Brushless Inrunner Motor (included)
Electronic Speed Control
120A with 8A/BEC (included)
Propeller / EDF
12-Blade EDF (included)
Servos
9g digital hybrid gear servo with 200mm lead : nose gear steering, landing gear door - MD31093-200
9g digital gear servo with 400mm lead : left canard, right canard - MD31092-400
9g digital hybrid gear servo with 500mm lead : rear cabin door left - MD31093-500
9g digital hybrid reverse gear servo with 500mm lead : rear cabin door right - MD31093R-800
17g digital metal gear servo with 100mm lead : rudder - MD31172-100
17g digital metal gear servo with 300mm lead : left aileron, right aileron - MD31172-300
Landing Gear
Electronic, CNC retractable scale gear
Required Battery
TWO 4 Cell 14.8V 6000 mAh LiPo batteries with EC5 connector OR
ONE 6 Cell 22.2V 5000 mAh LiPo battery with EC5 connector AND ONE 2 Cell 7.4V 5000 mAh LiPo with EC5 connector (required)
Required Radio
7+ Channel (required)
Ailerons
Elevons
Elevator
Elevons
Rudder
Yes
Flaps
No
Lights
Yes
Hinge Type
Nylon
Material
EPO Foam
Skill Level
Advanced/Expert
Build Time
3 Hours
Recommended Environment
Outdoors
