Tattu Semi Solid State 350Wh/kg 33000mAh 10C 22.2V 6S1P G-Tech Lipo Battery Pack with XT90-S plug

Manual Video Spare Parts The Tattu Semi-solid state 330Wh/kg 25000mAh 22.2V 10C 6S1P G-Tech Lipo Battery is a revolutionary semi-solid lithium battery, featuring high energy density and long service life. Compared with traditional lithium batteries, Tattu Semi-solid State battery has a higher energy and lighter weight, can increase the battery endurance by 30% and cycle life more than of 500 (90% initial capacity). It is an ideal power solution for various industrial drones, including those used in mapping, inspection, surveying, delivery, and eVTOL applications. These drones typically require a nominal discharge current of 1-3C, and this battery’s lightweight design, compact size, and extended flight time fully meet those demands. Specifications: Capacity: 33000mAh Voltage: 22.2V/6S Max Peak Current: 10C Net Weight: 2355g(±20g) Size:213*91*61mm Discharge Connector Type: XT90-S Balancer Connector Type: G-Tech-7P Features: Energy Density: *350Wh/kg – This is a high energy density, suitable for applications where weight and energy storage are critical. Safety Performance: *Voltage Range: From 4.2V to 2.75V when SOC is from 100% to 0%. This range suggests good safety management within the battery’s operating limits. Discharge Rate: *Max Peak Current: 10C (for < 3 seconds) *These rates indicate the battery’s ability to deliver power quickly and efficiently. Cycle Life: *Over 500 cycles – The battery maintains its performance over a significant number of charge-discharge cycles. G-Tech Functionality: The battery supports the G-Tech function with the Tattu TA1000 1000W charger. It includes automatic current allocation, enhancing charging efficiency and battery management. Technical Features: *Ultra-High Nickel Technology: Likely contributes to higher energy density and overall battery performance. *Silicon Carbon Anode: Enhances the battery’s capacity and cycling stability. *Coated Diaphragm Technology: Improves safety and performance by enhancing the separator's strength and stability. *Solid Electrolyte: Offers improved safety and performance, reducing the risk of leakage and enhancing the battery's life. These features suggest a battery designed for high-performance applications, such as drones, electric vehicles, or other advanced electronics. If you have any specific questions or need further details, feel free to ask! Brand: TATTU Capacity(mAh): 33000 Voltage(V): 22.2V Configuration: 6S1P Discharge Rate (C): 10C Connector Type: XT90-S Length(±5mm): 213 Width(±2mm): 91 Height(±2mm): 61 Net Weight(±100g): 2355g Discharge Wire Length(mm): 150mm Wire Gauge: 8# Balancer Connector Type: G-Tech-7P Balancer Wire Length(mm): 85mm Quantity per box: 6pcs/box
