3W-80Xi Engine 8.5 HP Power

Manual Video Spare Parts Powerful single-cylinder engine The engine is very well suited for aerobatics, towing, or scale models. With its low vibration level for single-cylinder engines, it is especially appropriate for aerobatics machines in the 10 kg class. Due to the matched 3W muffler system, the engine is comparable to other manufacturers’ 100 ccm en-gines because the performance data are analogous. The engine is suitable for a broad variety of models and distinguishes itself through its reliability and durability. The microprocessor-controlled ignition enables simple engine control. The programmed ignition curve is exactly matched to the engines and guarantees good running characteristics in all rotation-al-speed ranges. The standard ignition can be operated with a voltage of 6 V up to 8.4 V (2-cell LiPo). Cylinder capacity 78.00 ccm Power 8.5 HP / 6.25 KW Bore diameter 50.00 mm Stroke 40.00 mm Rpm range 1.100 – 8.500 U/min-1 Weight incl. ignition 2.375 kg incl. ignition Crankshaft 3 ball bearing Oil/gasoline ratio 1:50 / 2% Mix Ignition 6.0 – 8.4 V DC
