Ev-peak DC Balance charger Q6

Manual Video Spare Parts It is a quad DC charger, it could charge four packs of batteries at the same time and disply data of each port singly. With four independent output port and in temp. port you could connect charger and PC with USB software kits to monitor battery performance. With 11-18V DC input and two cooling fans, could advoid charger over heat. Create a safe charging condition and maximum reduce the danger caused by negligence or setting error of user. High efficiency up to 90%. Accept all types of R/C batteries: LiPO/LiFe/NiMH/NiCd/Pb. Easy to operate. It can monitor and balance each cell of the pack individually ( tolerance ±0.01V). Accept individual battery charging/discharging. Various of charging mode to meet different demand. It can store and load maximum five data of different batteries. Perform 1-5 cycles of charge>discharge or discharge>charge continually for NiMH/NiCd refreshing PC program, you can analysis the characteristic of the battery by USB port. Specification: DC Input voltage: 11-18.0V Charge power: max. 50Wx4 Discharge power: max.5Wx4 Charge current range: 0.1-5.0A Discharge current range: 0.1-1.0A Balance tolerence: ±0.01V NiCd/NiMH battery cell count: 1 – 15 cells LiPo/LiLo/LiFe battery cell count: 1 – 6 series Pb battery voltage: 2 V – 24V Digital Power: 3V – 24V Includes: charger Q6, adapters set, set of cables, removable terminals of the "crocodile", manual.
