Freewing F-16 V2 90mm EDF Jet – ARF PLUS

Manual Video Spare Parts Freewing F-16 V2 90mm EDF Jet – ARF PLUS Model Scale 1/10 Scale Wingspan 955mm / 37.6in Length 1457mm / 57.4in Empty Weight 6S – 3.17kg (7.0lbs) 8S – 3.30kg (7.27lb) (without battery and without armament) CG (Center of Gravity) 110mm (4.3") from the leading edge of the wing at the root Power System 3668-1960 Kv Inrunner Motor (6S) or 4075-1350Kv Inrunner Motor (8S) (required) Electronic Speed Control 120A Brushless with 7A UBEC, thrust reversing, EC5 Connector (required) Propeller / EDF 90mm 12-Blade EDF (required) Servos 9g hybrid digital standard with 300mm lead : nose gear steering – MD31093-300 9g hybrid digital standard with 400mm lead : nose gear door – MD31093-400 17g metal gear digital standard with 100mm lead : left rudder, right rudder – MD31172-100 23g metal gear digital reverse 100mm lead : right elevator – MD31231R-100 23g metal gear digital standard 100mm lead : left elevator – MD31231-100 17g metal gear digital standard with 200mm lead : left flap, right flap – MD31172-200 17g metal gear digital standard with 300mm lead : left aileron, right aileron – MD31172-300 Landing Gear Electronic retractable main gear and steerable nose gear with all metal shock absorbing struts Required Battery 6S 22.2V 5000mAh LiPo with EC5 connector (required) Required Radio 6 Channel (required) Ailerons Yes Elevator Yes Rudder Yes Flaps No Lights Yes Hinge Type Nylon Reinforced Material EPO Foam Skill Level Intermediate/Advanced/Expert Build Time 1 Hour Recommended Environment Outdoor, 150+ foot paved runway or short manicured grass Version Note: This is the ARF+ version for pilots who wish to install their own power system. All primary electronics including servos and landing gear retracts come pre-installed, just add your own power system (EDF, motor, and ESC) to begin flying. The next-generation F-16C 90mm EDF from Freewing showcases a range of performance and design upgrades that elevate realism, flight capability, and convenience. Featuring a striking 64th Aggressors Livery, this model honors the distinguished 64th Aggressor Squadron, part of the legendary Aggressor program initiated in 1972. This squadron played a crucial role in training pilots through dissimilar air combat tactics, emulating potential adversaries. With quick-release wings, an easier fuselage assembly, and a slide rail system for armament, the updated F-16C 90mm prioritizes ease of use. Additionally, the scale appeal and functionality have reached new heights with fully functional, servo-driven air brakes, updated scale details, extra molded-in rivets, painted landing gear, and other intricate detail components. The Freewing F-16C 90mm is designed to impress. Experience the thrill and precision of the Freewing F-16C 90mm EDF – a true tribute to its full-scale counterpart, bringing advanced aerodynamics and stunning detail to your collection. Features: NEW! 64th Aggressors Camo Livery: A striking, historically inspired camouflage design NEW! Screwless, Quick-Release Main Wings: For easy assembly and transport NEW! Scale, Servo-Driven Air Brakes: Enhances scale realism and performance NEW! Quick Attach Rail System: Simplifies fuel tank and armament attachment NEW! Additional Molded-In Scale Rivet and Panel Details: Adds to the model’s scale appeal and authenticity NEW! Increased Battery Compartment Size: Accommodates larger batteries NEW! Plastic Corner Protection: Around the battery compartment and fuselage chines for added durability NEW! Additional Plastic Scale Details Included: Enhances the model’s visual appeal NEW! Spring-Loaded Cheater Holes: Improves power, speed, and overall performance NEW! Stronger Landing Gear Mounts and Painted, CNC-Machined Landing Gear: Adds scale aesthetic appeal and adds durability NEW! Spring-Loaded Battery Latch: Secures the battery with ease NEW! Glueless Rear Fuselage Assembly: Simplifies the build process Officially Licensed by Lockheed Martin Sequenced gear doors provide added realism and reduced drag Bright LED navigation and landing lights for enhanced realism and dawn/dusk maneuvers Carbon fiber wing spars Ball linkages on all control surfaces Nylon hinges on all control surfaces Includes: Freewing F-16 V2 90mm EDF Jet – ARF PLUS Electronic retractable landing gear (installed) Servos, LED Lights (installed) 64th Aggressor Squadron Livery Featuring an iconic 64th Aggressor Squadron livery, the Freewing F-16C showcases the legendary training unit. Quick Release Wings Enjoy effortless assembly and disassembly with the innovative quick release wing system. Scale, Servo-Driven Airbrakes Enhanced realism with fully functional, servo driven airbrakes that can be controlled from the transmitter. Powerful 6S or 8S Options Available As an ARF PLUS model, you can choose to role with the 8S version with the 4075 1350Kv inrunner motor and 120A ESC or 6S 3668-1960Kv inrunner motor. Both have ample power for your needs. Spring Loaded Cheater Holes Equipped with spring loaded cheaters that actuate in flight for enhanced in flight performance while maintaining scale appeal on the ground. Quick Attach Rail System for Armament Easily install and remove armament with the updated quick attach rail system. Added Scale Details Extra molded-in rivets and detailed plastic components elevate the scale realism. Larger Battery Compartment Spacious battery compartment to easily accommodate various battery sizes and configurations for 6 or 8S LiPo systems.
