LID B2H70cc HF UAV Engine TBO 300H w/cooling & mounting system Optional One Key Starter/Generator 24V/400W

Manual Video Spare Parts * two cylinders horizontally opposed; (engine was approved & integrated with many branded VTOLs worldwide) * Two strokes; * Air cooling; * electronic closed-loop control; * Dual redundant speed sensors * Optional enlightening motor/generator * Independent development of engine, ECU and fuel pump; * Better environmental adaptability; * Lower specific fuel consumption to meet the needs of long endurance; * Engine thermal management technology to ensure engine * The body is always in an appropriate temperature range; * Easier to use; * Higher durability reliability; 24/7 Technical support by teamaustars for protocol integration and support Model number :B2H70 Displacement :70ccm Maximum power :6HP Speed range :1800 to 8500rpm Applicable fuel :RP-3 Minimum specific fuel consumption: 405g/kwh Fuel system: Electronic control Ignition system: Electronic control Lubrication mode: mixed lubrication of fuel oil and lubricating oil, lubricating oil/fuel oil ratio: 1:50 Cooling method: Air cooling Throttle control mode: throttle electronic control Applicable temperature :-30 Celsius ~+55 Celsius Starting altitude 4000 meters Output axis rotation: counterclockwise (from the end of the output axis) Weight composition Engine body :2600 g ECU: 169 g Fuel pump :213 g CDI :159 g Wiring harness :166 g Exterior dimension Length x width x height: 195.4 x 262.5 x 270.5mm Other configurations are optional Damping system Inspired integrated configuration/generator configuration Recommended propeller specification Two blades: 24×10, 24×12, 24×14, 22×12, 22×14 Three-bladed paddle: /
