NAJA E-EYE 3600 Composite construction H-tail V-tail FPV/UAV Platform w/Power System Options

Manual Video Spare Parts Description Technical Data: (Fiberglass fuselage & wing) Wingspan: 3600mm (Different batch might have a slight difference) Length: 2488mm Wing Area: 133dm2 Flight time: Depending on your particular flying style. Minimum speed: 45km/hr Empty Weight: 12.9kg (Different batch might have a slight difference) Take-off weight: 28 kg Max. Flight Time: 3 Hours Engine: 50-100cc Fuel Capacity: 6.5 Liters Payload: Full of oil can also carry 5-8 kg Full load takeoff distance: 50 meters Landing distance: 70 meters Propeller: 23*10 Fuselage Cabin(L*W*H): 560*260*270(mm) Type: Two-stroke piston valve petrol aircraft engine Displacement: 55cc(27.2ccx2) Bore x Stroke: 34mm×30mm Carburetor: Walbro(Diaphragm & Butterfly Valve) Max. Output: 5.6ps/7600rpm RPM Range: 1600-7800rpm Weight: About 1780g?Engine+muffler+CDI? Ignition power: Auto advanced CDI(DC 4.8 Volts , 4 cell NiCad or NiMh battery) Fuel mixture(Ratio of gasoline and oil): 25-40 : 1 Propeller: 20X12-23X8 two-blade prop( suggest to use 22×8 prop) For your easier build, it also comes in two power packages, either in electric or gasoline powered, so you do not need to spend hours of research looking for everything you need to get this plane in the air. Just assemble and you are ready to go. Gasoline Power Package 8x SC-1256TG servo 1x DLE60C engine 1x 23*9 High Power Propeller 1x UAV Pitot (Airspeed tube) 1x LEG Lights for Navigation Electric Power Package 1x Dualsky GA6000.8 180RPM/V Brushless Motor 1x Dualsky XC13036HV 130A High Voltage ESC 7x Savox 1256 Servo 1x 24*12 High Power Propeller w/ Prop Cover 1x UAV pitot (airspeed tube) 1x LED lights for navigation
