Product technical parameter

Manual Video Spare Parts Product technical parameter Thrust:80kg Diameter:207mm Length:455mm Weight:9260g Speed range:25000-65000 Idle RPM:25000 Rated exhaust Max Temp:750°C Fuel consumption:≤1850g/min Fuel used:Aviation kerosene Lubricating oil: 3%-5% Maintenance cycle: 25H Engine start Engine operation Starting motor Pump Voltage 0.6-0.76V RPM ACC 10 Eject time 0.8S RPM Start Up Ramp 100 RPM DEC 10 Ejection Low Volt 5V Pump Start Up Ramp 2 Idle RPM range 15000?65000 Run Voltage 2.5V Glow Plug 5-7.6V Idle RPM 25000 RPM Stable 20 Valve 10-40 Max Temp ≤1000 Cooling 2000 Ignition RPM 1300 Low Volt ≥10V Preheat RPM 2000 Restart Off RPM Off Starter 13000 Restart Glow Plug Consistent with the fire head Low Volt Pump Limit 20V Ldle Stable 5-8 High power brushless starting motor The brushless starting motor developed by ourselves has stable output, reliable operation and long service life Brushless, low interference:The brushless motor removes the brush, thereby avoiding the electrical spark generated by the operation of the brushed motor. This not only greatly reduces the interference of electric sparks to remote control wireless equipment, but also provides a more stable working environment for the equipment. Good Speed range control performance:The brushless motor has the characteristics of wide Speed range regulation range and low error of high steady Speed range, which makes it have significant advantages in the field of Speed range regulation. The controller of the brushless motor can adjust the Speed range of the motor according to the need to achieve good working condition. Small size, light weight:The small size and light weight of the brushless motor make it more flexible and convenient in design and installation. Low power consumption, high efficiency:The power consumption of brushless motors is usually only one-third of that of brushed motors, while their efficiency is also relatively high. This means that at the same power, brushless motors are able to provide greater torque and higher Speed range, while reducing energy consumption. Low noise, smooth operation:Because there is no brush, the friction of the brushless motor is greatly reduced during operation, making it run more smoothly and the noise is relatively low. High reliability:Brushless motors have no wearing parts such as brushes, so their reliability is higher. Oil system connection Compatible with various types of engines, such as SW190B, SW220B, SW300B, SW400Pro, with ECU can accurately control the amount of fuel, ignition timing, etc., in order to achieve stable engine operation. Compact structure and small size Compact structure, small size, precise design and small space, suitable for installation in a limited space. Strong self-priming ability Strong self-priming ability, regardless of high, low Speed range and even manual conditions can be reliably self-priming. Strong applicability Strong applicability, can be pumped into high viscosity oil night, suitable for all kinds of oil, lubricating oil and so on. Reliable operation and stable operation It has the advantages of long life and low failure rate. Later maintenance is convenient, and maintenance and repair costs are low. Convenient post-maintenance Later maintenance is convenient, and maintenance and repair costs are low. Suitable for a variety of Max Temps It can work stably in the environment of -40°C to +50°C, and the flow rate is uniform and the oil pressure is stable. Highly intelligent, convenient and reliable With the characteristics of high intelligence, it can automatically identify user needs and provide personalized services Starting height6500m + Flight altitude12000m + SW800Pro-Y Engine Accessories List (Per Set)
