QRS B2H 183cc HF UAV/UAS Engine TBO300H w/One Key Starter/Generator 24V/800W + Support ArduPilot PNP

Manual Video Spare Parts The 183CC engine is an air cooled horizontally opposed piston engine with dual- redundant TCI ignition. Compared with its counterparts in the market,the engine is light weighted, consistent in performance, robust and maintenance friendly. 183CC is an ideal choice to power fixed-wing UAV and VTOL of MTOW 60kg~120kg TEAM AUSTARS PROVIDE 24/7 TECHNICAL SUPPORT WITH COM/PROTOCOL FOR AUTOPILOT INTEGRATION. FREE CUSTOMISED ENGINE MOUNTING FRAME TO FIT EACH PROJECT PRICE SHARPLY WAS DROPPED DUE TO MASS PRODUCTION AND MARKET DEMAND! Technical Parameter Configuration 2Cyl. Horizontally Opposed Displacement 183ml Bore × Stroke 54m×40m Speed Range 2000rpm~6700rpm Compression Ratio 10.1:1 Lubrication Oil Gas Lubrication Fuel Delivery Electronic Fuel Injection Fuel Type 3# JET Fuel (or 92# Gasoline and Above, Aviation Gasoline) Starting Method External Starter Starting, Integrated Starter Starting Starting Conditions Cylinder Temperature ≥ 85 Celsius (JET Fuel),Throttle Position ≥ 25% Weight 6.5 Fuel Consumption 450/kW·h Rated Power 10.5kW@6500rpm Generator Customized
