SKY POWER SP-55cc (3W Intl) UAV FI/EFI TS/ROS Engine,W/Generator, HF Versions

Manual Video Spare Parts SKY POWER SP-55 FI/EFI TS ROS Engine (PRODUCTON 2-4 WEEKS) TS: TWIN SPARK ROS: REAR OUTPUT SHAFT FI=FUEL INJECTION FI VERSION INCLUDES STAINLESS STEEL EXHAUST The single cylinder engine of the SP-55 series is designed with twin spark plugs and can be equipped with a carburetor or a fuel injection. The rear output shaft and the position of the carburetor or the fuel injection on the side, make this engine to one of the most compact 1-cylinder engines on the market. Because of the rear output shaft, a generator can be mounted on the back of the engine. All fuel injected engines are equipped with the ignition HKZ215 and the ECU030. General series specifications range Type 1-Cylinder Gas-Engine Capacity 55 ccm / 3.35 cu in Power 4.18 HP / 3.1 KW Speed Range 2000 – 10000 RPM (depending on version) Weight SP-55 TS = 2580 gramm / 5,69 lbs (incl. ignition) SP-55 FI TS ROS = 3500 gramm / 7,72 lbs (incl. ignition, ecu, fuel pump) Crankshaft 4 ball bearings Oil/Gasoline ratio 1:50 / 2% mix Operating Voltage 6 – 8.4 V DC
