Tattu Semi solid 22000mAh 5C 22.2V 6S1P XT90S-F G-Tech Lipo Battery

Manual Video Spare Parts Battery Specifications: Capacity: 22000mAh Voltage: 22.2V/6S Max Constant Current: 3C Max Peak Current: 5C Net Weight: 2250g (±20g) Size: 191*76.5*64mm Discharge Connector Type: XT90-S Balancer Connector Type: G-Tech-7P Features: Energy Density:271.33Wh/kg – This is a high energy density, suitable for applications where weight and energy storage are critical. Safety Performance:Voltage Range: From 4.2V to 2.75V when SOC is from 100% to 0%. This range suggests good safety management within the battery’s operating limits. Discharge Rate: Max Constant Current: 3C Max Peak Current: 5C (for < 3 seconds) These rates indicate the battery’s ability to deliver power quickly and efficiently. Cycle Life: Over 500 cycles – The battery maintains its performance over a significant number of charge-discharge cycles. G-Tech Functionality: The battery supports the G-Tech function with the Tattu TA1000 1000W charger. It includes automatic current allocation, enhancing charging efficiency and battery management. Technical Features: Ultra-High Nickel Technology: Likely contributes to higher energy density and overall battery performance. Silicon Carbon Anode: Enhances the battery’s capacity and cycling stability. Coated Diaphragm Technology: Improves safety and performance by enhancing the separator's strength and stability. Solid Electrolyte: Offers improved safety and performance, reducing the risk of leakage and enhancing the battery's life. Brand: TATTU SKU: TARB1122K0605X Capacity(mAh): 22000 Voltage(V): 22.2V Configuration: 6S1P Discharge Rate (C): 5C Connector Type: XT90S Length(±5mm): 191 Width(±2mm): 76.5 Height(±2mm): 64 Net Weight(±100g): 2250g Discharge Wire Length(mm): 150mm Wire Gauge: 8# Balancer Connector Type: G-Tech-7P Balancer Wire Length(mm): 65mm
