Tattu Semi solid State 300Wh/kg 17000mAh 10C 22.2V 6S1P G-Tech Lipo Battery Pack with XT90S-F

Manual Video Spare Parts Battery Specifications: Capacity: 17000mAh Voltage: 22.2V/6S Max Peak Current: 10C Net Weight(±20g): 1432g Size: 193*71*50.5mm Discharge Connector Type: XT90S-F Balancer Connector Type: G-Tech-7P Discharge Wire: 8# 150mm Charge Wire: 22# 65mm Features: Energy Density: 300Wh/Kg – This is a high energy density, suitable for applications where weight and energy storage are critical. Safety Performance: Voltage Range: From 4.2V to 2.75V when SOC is from 100% to 0%. This range suggests good safety management within the battery’s operating limits. Discharge Rate: Max Constant Current: 3C Max Peak Current: 5C (for < 3 seconds) These rates indicate the battery’s ability to deliver power quickly and efficiently. Cycle Life: Over 500 cycles – The battery maintains its performance over a significant number of charge-discharge cycles. G-Tech Functionality: The battery supports the G-Tech function with the Tattu TA1000 1000W charger. It includes automatic current allocation, enhancing charging efficiency and battery management. Technical Features: Ultra-High Nickel Technology: Likely contributes to higher energy density and overall battery performance. Silicon Carbon Anode: Enhances the battery’s capacity and cycling stability. Coated Diaphragm Technology:Improves safety and performance by enhancing the separator's strength and stability. Solid Electrolyte:Offers improved safety and performance, reducing the risk of leakage and enhancing the battery's life. Brand: TATTU Capacity(mAh): 17000 Voltage(V): 22.2V Configuration: 6S1P Discharge Rate (C): 10C Connector Type: XT90S Length(±5mm): 193 Width(±2mm): 71 Height(±2mm): 50.5 Net Weight(±100g): 1432g Discharge Wire Length(mm): 150mm Wire Gauge: 8# Balancer Connector Type: G-Tech-7P Balancer Wire Length(mm): 65mm
