UAV VTOL Herlea 265kg Thrust Motor UN233S Combo w/400V/160A ESC & 1X 78″ Propeller for eVTOL projects

Manual Video Spare Parts UAV VTOL Herlea 265kg Thrust Motor UN233S Combo w/400V/160A ESC & 1X Propeller 78 inch Motor Model: UN233S KV: 13KV No-load current: 1.5A/30V Motor weight:14000 g Maximum current:158A Maximum tension:265kg Electrical recommendation:ESC 400V 150A Dual mode Rated operating voltage:400V Interphase internal resistance:250mΩ Leakage current:10mA Maximum power:62454W Maximum torque:265Nm Propeller recommendation:JXF78 two leaf 400V 160A PRO ESC Support 400V high voltage platform, specially for super heavy load Man-machine customized. The third generation semiconducting material is silicon carbide (SiC) MOS tube, as well as mature new energy vehicle drive architecture design, so that it has the advantages of high power density and high efficiency. Equipped with 12V/1A BEC output for easy integration. The mature and reliable sensorless FOC algorithm, combined with many years of market verification, forms a perfect development verification system, and promotes high reliability of products. Product parameter Model: FF4009 Power modulation type: FOC Recommended tension: 80~90kg Recommended battery: 96~100S LiPo Rated output power: 30KW Voltage range: 200V~435V Continuous output current: 160A Peak output current: 320A (10S) Maximum speed: 4800RPM(20 poles) Ambient temperature: -40~50°C Waterproof rating: IP67 Cooling method: forced air cooling BEC: 12V/1A Fixed propeller function: Supported Motor temperature detection: PT1000 Weight (excluding wire) : 1.7kg PWM input level: 3.3V/5V PWM input pulse width: 200~2000uS PWM input frequency: 5O~5OOHz Communication interface: CAN*2 (CAN2.0B, 1M bps) Digital communication throttle: Supported Firmware upgrade: Supported Electrical protection strategy: 1. Locked-rotor protection, overcurrent protection; 2. Short circuit protection, overvoltage protection; 3. Undervoltage protection, input signal identification; 4. Overheat power protection, throttle loss protection PWM PWM Pulse Width (uS) Motor speed Forward Direction 1100 ~ 1900 Idle speed to full throttle speed Forward Direction 1900 ~ 2400 Full throttle speed Stop Other Pulse 0 RPM *Idle speed: The minimum speed, for example, 300RPM, can be set on the firmware. *Full throttle maximum speed: The maximum speed, such as 5000RPM, can be set on the firmware. Firmware upgrade 1. Upper computer: Sinemotion Tool 2. Upgrader: USB to CAN; 3. Battery or DC power supply; Method 1. Connect USB to CAN converter between PC and ESC using CANH, CANL and GND; 2. Power on the power supply. 3. On the Firmware page of the ESC test tool, select the serial port, select the firmware file, and click Update. 78 inch Propeller
