UMS 9-115CC PETROL RADIAL ENGINE

Manual Video Spare Parts Video filmed by Morris Mini Motor Team with Thanks! TWO AVAILABLE FOR CHRISTMAS SALES. The UMS 9-115 is a very reliable radial engines which uses gasoline fuel. UMS has a ton of experience building radial engines. It has brought more than 2000 engines to market so far. The design and construction are upper class leading to a outstanding realibility of these engines. They are easily servicebale. All critical parts are easily accesisble. SPECIFICATION Type SPARK IGNITION Cylinder Type 9 (ABC TYPE) Bore 25.1MM Stroke 26MM RPM Range 1000-6000 Weight of Engine 4000g incl.(ignition coil & silencer) Engine Diameter 260MM Length 170MM Prop Range 24X8,24X10,24X12 Muffler Type COLLECTOR RING Plug Type 1/4-32 RcExl Carburetor WALBRO WT-621 Weight of Silencer 3.5KG Power 7.6 HP Thrust 12.5kgf @ 24X10 MENZ PROP. Tank Capacity 115CC
