JHEMCU GF16 13A ECS (500 X Pack)

Manual Video Spare Parts ESC parameters: 1. Input voltage: 2-4S LiPo/2-4S HV LiPo 2. BEC output: none 3. Continuous working current of a single ESC: 13A*4 4. External ESC size: 24*25mm (including the maximum size of pads and protruding points) 5. Screw hole pitch 16*16MM, aperture 3MM 6. Firmware: BLHELI_S G_H_30_16_7.HEX 7. Support Dshot600, Dshot300, Dshot150, Oneshot125, Multishot, PWM control signals Weight: flight control + ESC = 5.8 grams Packing list: GF16-F405 flight control *1 GF16-ESC Four-in-one ESC *1 M2*20 screw *4 M2*5 shock absorbing ball *8 M2 nut *4 18AWG wire *2 220UF/25V capacitor *1 XT30 *1
