QRS B2G 312cc EFI UAV/UAS Engine TBO300H w/One Key Starter/Generator 24V/2000W +Support ArduPilot PNP

Manual Video Spare Parts The 312CC engine is an air cooled horizontally opposed piston engine with dual-redundant TCI ignition. Compared with its counterparts in the market,the engine is light weighted, consistent in performance, robust and maintenance friendly. 312CC is an ideal choice to power fixed-wing UAV and VTOL of MTOW 120kg~ 200kg. FOR PROTOCOL INTEGRATION, CONTACT TEAM AUSTARS TO GET 24/7 TECHNICAL SUPPORT BY WHATSAPP PRICE SHARPLY WAS DROPPED DUE TO MASS PRODUCTION AND MARKET DEMAND! THIS ENGINE IS UNDER EXPORT CONTROL Technical Parameter Configuration 2Cyl. Horizontally Opposed Displacement 312ml Bore × Stroke 65mm×47mm Speed Range 1600rpm~7000rpm Compression Ratio 10.6:1 Lubrication Oil Gas Lubrication Fuel Delivery Electronic Fuel Injection Fuel Type 3# JET Fuel (or 92# Gasoline and Above, Aviation Gasoline) Starting Method External Starter Starting, Integrated Starter Starting Starting Conditions Cylinder Temperature ≥ 85 Celsius (JET Fuel),Throttle Position ≥ 25% Weight 10.8kg Fuel Consumption 410g/kW·h Rated Power 18.4kW@6700rpm Generator Customized
