QRS B2H 312cc HF UAV/UAS Engine TBO300H w/One Key Starter/Generator 24V/2000W + Support ArduPilot PNP

Manual Video Spare Parts The 312CC engine is an air cooled horizontally opposed piston engine with dual-redundant TCI ignition. Compared with its counterparts in the market,the engine is light weighted, consistent in performance, robust and maintenance friendly. 312CC is an ideal choice to power fixed-wing UAV and VTOL of MTOW 140kg~ 200kg. FOR PROTOCOL INTEGRATION, CONTACT TEAM AUSTARS TO GET 24/7 TECHNICAL SUPPORT THIS IS HEAVY FUEL VERSION PRICE SHARPLY WAS DROPPED DUE TO MASS PRODUCTION AND MARKET DEMAND! THIS ENGINE IS UNDER EXPORT CONTROL Technical Parameter Configuration 2Cyl. Horizontally Opposed Displacement 312ml Bore × Stroke 65mm×47mm Speed Range 1600rpm~7000rpm Compression Ratio 10.6:1 Lubrication Oil Gas Lubrication Fuel Delivery Electronic Fuel Injection Fuel Type 3# JET Fuel (or 92# Gasoline and Above, Aviation Gasoline) Starting Method External Starter Starting, Integrated Starter Starting Starting Conditions Cylinder Temperature ≥ 85 Celsius (JET Fuel),Throttle Position ≥ 25% Weight 10.8kg Fuel Consumption 410g/kW·h Rated Power 18.4kW@8000rpm Generator Customized
