Manual Video Spare Parts Turbojet engine SW800Pro Product technical parameter Thrust:120kg Diameter:240mm Length:442.6mm Weight:16000g Speed range:22000-50000 Idle RPM:22000 Rated exhaust Max Temp:750°C Fuel consumption:≤2780g/min Fuel used:Aviation kerosene Lubricating oil: 3%-5% Maintenance cycle: 25H Engine operating parameter Engine operating parameter Engine operating parameter Pump Voltage 3V-4V RPM ACC 10 Cooling 1200rpm RPM Start Up Ramp 80% RPM DEC 10 Eject time 0.8S Pump Start Up Ramp 1 Rotational Speed range 22000?50000 Ejection Low Volt 3.5V Glow Plug 5-7.6V Idle RPM 20000 Run Voltage 4V Valve 40 Max Temp ≤900 RPM Stable 20 Ignition RPM 1200 Low Volt ≥10V Preheat RPM 5000 Restart Off RPM Off Starter 8000 Restart Glow Plug Consistent with the fire head Low Volt Pump Limit 24V Ldle Stable 8 Independent development of ECU control system Compatible with various sensor data of the engine, key parameters such as fuel amount, ignition timing and brushless motor can be accurately controlled to achieve stable operation of the engine. It can be paired with a quick-start engine such as the 800pro and is up and running in 10 seconds. Strong compatibility Compatible with various sensor data of the engine, key parameters such as fuel amount, ignition timing and brushless motor can be accurately controlled to achieve stable operation of the engine Fault diagnosis Record the diagnosis of engine failure, when the failure occurs, the alarm is issued, and the relevant fault code is stored in its internal memory chip, so that technicians can troubleshoot and repair Energy saving and drainage Precise control of fuel injection and ignition timing can achieve fuel combustion and emission reduction, thereby improving fuel economy and reducing tailpipe emissions Monitor external environment Monitor parameters such as Max Temp and pressure of the external environment to adapt to different working environments. Use at extreme Max Temps, such as ambient Max Temps of -40 ° C, or +50 ° C Performance adjustment The ECU can adjust the performance of the engine by modifying the internal program and upgrading the program to meet different needs Sensor and actuator TCU ECU can not only read the data of the sensor, but also control the operation of the actuator TCU High power brushless starting motor The brushless starting motor developed by ourselves has stable output, reliable operation and long service life Brushless, low interference:The brushless motor removes the brush, thereby avoiding the electrical spark generated by the operation of the brushed motor. This not only greatly reduces the interference of electric sparks to remote control wireless equipment, but also provides a more stable working environment for the equipment. Good Speed range control performance:The brushless motor has the characteristics of wide Speed range regulation range and low error of high steady Speed range, which makes it have significant advantages in the field of Speed range regulation. The controller of the brushless motor can adjust the Speed range of the motor according to the need to achieve good working condition. Small size, light weight:The small size and light weight of the brushless motor make it more flexible and convenient in design and installation. Low power consumption, high efficiency:The power consumption of brushless motors is usually only one-third of that of brushed motors, while their efficiency is also relatively high. This means that at the same power, brushless motors are able to provide greater torque and higher Speed range, while reducing energy consumption. Low noise, smooth operation:Because there is no brush, the friction of the brushless motor is greatly reduced during operation, making it run more smoothly and the noise is relatively low. High reliability:Brushless motors have no wearing parts such as brushes, so their reliability is higher. Oil system connection Compatible with various types of engines, such as SW190B, SW220B, SW300B, SW400Pro, with ECU can accurately control the amount of fuel, ignition timing, etc., in order to achieve stable engine operation. Compact structure and small size Compact structure, small size, precise design and small space, suitable for installation in a limited space. Strong self-priming ability Strong self-priming ability, regardless of high, low Speed range and even manual conditions can be reliably self-priming. Strong applicability Strong applicability, can be pumped into high viscosity oil night, suitable for all kinds of oil, lubricating oil and so on. Reliable operation and stable operation It has the advantages of long life and low failure rate. Later maintenance is convenient, and maintenance and repair costs are low. Convenient post-maintenance Later maintenance is convenient, and maintenance and repair costs are low. Suitable for a variety of Max Temps It can work stably in the environment of -40°C to +50°C, and the flow rate is uniform and the oil pressure is stable. Highly intelligent, convenient and reliable With the characteristics of high intelligence, it can automatically identify user needs and provide personalized services Starting height6500m + Flight altitude12000m + SW1200Pro Engine Accessories List (Per Set)
