3-Axis Gremsy R3 61PRO Camera System THAI

Manual Video Spare Parts PRODUCT INFO The 3-Axis Gremsy R3 61PRO Camera System consists of three components: 1. Gremsy 3-axis gimbal with quick attach-detach gimbal adopter(no damping plate). 2. Airpixel entire R3 for directly geotagging and Mavlink control. 3. ADTi 61MP full frame 61PRO camera (no lens). This camera system is designed for all the practical features of Ardupilot and PX4, it has: 61 megapixel full-frame Sony CMOS sensor. Compatible with any Emount full frame lenses Bionz X image processor. EXIF GPS directly geotagging from airpixel R3 MAVlink remote control Quick attach-detach smart gremsy gimbal system Reliable system for high quailty images total weight 1.0kg with damping plate (no lens) CAMERA SPECIFICATIONS Sensor Type:CMOS Sensor Manufacturer:Sony Effective Megapixels:61 Sensor Format:full frame Sensor size:849.6mm2 (35.7×23.8mm) Approximate Pixel Pitch:3.76 microns Focal Length Multiplier:1.0x Aspect Ratio:3:2 Color Filter Type:RGBG Anti Aliasing Filter:None Color Depth （bits):26 Maximum Effective ISO:3,344 Image Capture Image Resolution: 79504 x 6336 (60.2 MP, 3:2), 6240 x 4160 (26.0 MP, 3:2), 4752 x 3168 (15.1 MP, 3:2), 8448 x 6336 (53.5 MP, 4:3), 5552 x 4160 (23.1 MP, 4:3), 4224 x 3168 (13.4 MP, 4:3), 9504 x 5344 (50.8 MP, 16:9), 6240 x 3512 (21.9 MP, 16:9), 4752 x 2672 (12.7 MP, 16:9), 6336 x 6336 (40.1 MP, 1:1), 4160 x 4160 (17.3 MP, 1:1), 3168 x 3168 (10.0 MP, 1:1) Image File Format:JPEG, RAW (14-bit ARW 2.3), RAW+JPEG Continuous-mode frames/second:10.0 Video Capture Video Resolution: 3840×2160 (30p/​25p/​24p) 1920×1080 (120p/​100p/​60p/​60i/​50p/​50i/​30p/​25p/​24p) Video File Format:XAVC S / AVCHD 2.0 / MP4; Audio: LPCM / Dolby Digital (AC-3) / MPEG-4 AAC-LC, stereo HD Video Out:Yes HD Video Connection:HDMI Lens & Optics Lens Mount:Sony E Auto Focus: Yes Manual Focus: Yes Shutter Type:Mechanical shutter Speed:1/8000-30sec Camera Gimbal Camera（LxWxH): 18.2*16.5*16.5 cm Gimbal camera without lens Weight: 1000 g Package Weight: 2.5 kg Gremsy ADTI 3-axis gimbal Built-In Functions 1. Operation Modes: On/Off/Lock mode/Follow mode/Mapping mode 2. New generation IMU Sensor 3. Gremsy Specialized Gimbal Drive Motors with Encoders (Encoder 14 bits) 4. Airpixel R3 built-in PLATFORM SUPPORTED Drones/Flight Controllers Supported: Pixhawk/ Cube Pilot FC/ Skynode Camera Supported: ADTI 41L /ADTI 61PRO MECHANICAL & ELECTRICAL CHARACTERISTICS Working Current Static current: 500mA @14.5V Dynamic current: 1A @14.5V Locked motor current: Max 3.8A @14.5V Operating Temperature:14° F ~ 122° F (-10° C ~ 50° C) Gimbal Weight: 600g/ 1.2 lbs Gimbal Dimension (DxWxH): 140mm x 127mm x 183mm PERIPHERAL Damping Type: Pixy S Damping Gimbal Mount: Bottom Quick Release: WORKING PERFORMANCE Third Party Control: Sbus, Spektrum, MAVLink, LB2 AUX Signals: 4 signals Input power: 12V WORKING PERFORMANCE Angular Vibration Range: ± 0.02° Maximum Controlled Rotation Speed: Pan axis: 180°/s Tilt axis: 180°/s Roll axis: 180°/s Mechanical Endpoint Range: Pan axis control: -328° to +328° Tilt axis control: -140° to +50° Roll axis control: -290° to +50° Controlled Rotation Range: Pan axis control: ±320° Tilt axis control: -120° to 40° Roll axis control: ± 30° Airpixel Entire R3 (Build-in) 1. Build-in for gremsy and ADTI 61PRO (less wiring harness) 2. Directly geotagging on images as EXIF data 3. MAVlink control for PX4 or Ardupilot
