ADTi 24MP 24S V3 Surveyor Lite Drone Mapping Cameras THAI

Manual Video Spare Parts PRODUCT INFO 24S V3 Surveyor Lite Mapping Camera is ADTi's fourth generation of the 24MP APS-C Drone/UAV Mapping Cameras, it has ADTi SDK camera controlling system, that is compatible with airpixel for PIX4 and ardupilot MAVlink. comparing with ADTI 24L V1, V2, and 24S V2, this 24S V3 has twice faster shutter speed than anothers, which make it as good mapping camera option for fixed wing UAVs. It has serial mini touch screen that provides camera setting setup, and its HDMI video capture card allows to connect with any android devices to check the camera settings. it also features a swtich button that gives camera either TTL or PWM triggering options. It features: 1. light in weight (camera body 143 g) 2. compact in size (89.8* 63*36.2 mm ) 3. aluminum camera case 4. 24MP APS-C CAMERA SPECIFICATIONS Sensor Type:CMOS Sensor Manufacturer:Sony Effective Megapixels:24.3 Sensor Format:APS-C Sensor size:366.6mm2 (23.50mm x 15.60mm) Approximate Pixel Pitch:3.92 microns Focal Length Multiplier:3.13x Aspect Ratio:3:2 Color Filter Type:RGBG Anti Aliasing Filter:Fixed Color Depth （bits):24.1 Maximum Effective ISO:1,347 Image Capture Image Resolution: 6000 x 4000 (24.0 MP, 3:2), 6000 x 3376 (20.3 MP, 16:9), 4240 x 2832 (12.0 MP, 3:2), 4240 x 2400 (10.2 MP, Other), 3008 x 2000 (6.0 MP, 3:2), 3008 x 1688 (5.1 MP, 16:9), 12416 x 1856 (23.0 MP, Other), 8192 x 1856 (15.2 MP, Other), 2160 x 5536 (12.0 MP, Other), 2160 x 3872 (8.4 MP, Other) Image File Format:JPEG, RAW, RAW+JPEG Continuous-mode frames/second: 11.1 Video Capture Video Resolution: 1920×1080 (60p/​60i/​30p/​24p) 1440×1080 (30p) 640×480 (30p) Video File Format:XAVC S/AVCHD 2.0 / MP4 HD Video Out:Yes HD Video Connection:HDMI Lens & Optics Lens Mount:Sony E Normal Focus Range:25 cm to Infinity Auto Focus: Yes Manual Focus: Yes Display (detached) Power: 5V DC Buttons: No Screen Size: 2 inch mini touch screen Camera Camera Size: 8.9* 6.3*3.6 cm Camera Weight: 133 g Package Size: 30*20*15 cm Package Weight: 500 g Power: 10-25V DC Lipo or Liion Operating Temperature: -10 to 40°C
